The ICC A117.1 standard, titled Accessible and Usable Buildings and Facilities, serves as the primary technical reference for accessibility in the International Building Code (IBC). Designing compliant restrooms and bathing facilities requires strict adherence to its detailed provisions for clear floor space, fixture mounting heights, and maneuvering clearances.

‍

Here are the essential code requirements at a glance:

‍

• Turning Circle & Door Swing: The required 60-inch diameter turning circle must be kept clear of all obstructions. However, per ICC A117.1-2017 §304.4, it can overlap the arc of a door's swing. The space is considered usable when the door is in the closed position, allowing a user to enter, close the door, and then maneuver.
• Clear Floor Space Measurement: All clear floor space dimensions, such as the 30-inch by 60-inch space in a roll-in shower, are measured from the face of the finished surfaces (e.g., finished tile or wallboard), not from the rough framing. This is a critical distinction that can lead to non-compliance if not accounted for during design and construction.
• Toilet Seat Height: The height of an accessible toilet seat must be between 17 inches and 19 inches from the finished floor to the top of the seat (ICC A117.1-2017 §604.4).
• Shower Grab Bar Height: Horizontal grab bars in an accessible shower or bathtub must be mounted between 33 inches and 36 inches above the finished floor, measured to the centerline of the bar (ICC A117.1-2017 §609.4).

Fixture Counting: A properly configured single-user, unisex restroom that is fully accessible can count towards the total number of required plumbing fixtures for both men and women, as permitted by IBC 2024 §1110.2.1 and the International Plumbing Code.

Why ANSI A117.1 Compliance Matters

In the United States, accessibility is mandated by both building codes and federal law. The International Building Code (IBC) establishes the requirement for buildings to be accessible, but it primarily relies on a separate, detailed technical standard to define how to achieve that accessibility: the ICC A117.1. Concurrently, the Americans with Disabilities Act (ADA) is a federal civil rights law that also mandates accessibility, with its own technical document, the 2010 ADA Standards for Accessible Design.

For architects, engineers, and contractors, this means:

• The IBC requires compliance with A117.1. Plan reviewers and building inspectors will use ICC A117.1 as their primary reference for checking drawings and inspecting construction.
• The ADA is always in effect. Compliance with the IBC and A117.1 generally ensures compliance with the ADA, as the two standards have been closely harmonized. However, designers must ensure they meet the most stringent requirements of either standard.
• Non-compliance has consequences. Failure to meet these standards can result in failed inspections, costly rework, certificates of occupancy being withheld, and potential legal action under the ADA.

Mastering the nuances of A117.1 for restrooms and bathing facilities—one of the most complex and frequently used spaces—is not just about following rules; it's about ensuring safety, dignity, and equal access for all building occupants.

‍

In a multi-user restroom, does the required 60-inch turning circle have to be completely clear of the door swing, or can they overlap if the door is kept closed?

Yes, the 60-inch diameter turning circle can overlap the swing of the restroom door. The standard recognizes that the space occupied by the door's swing is available for maneuvering once the door is closed.

This is explicitly permitted by ICC A117.1-2017, Section 304.4 (Door Swing), which states that "door swings shall be permitted to overlap turning spaces." The key interpretation is that the clearance is evaluated with the door in the closed position. This allows for more efficient use of space in restroom design.

However, it's critical to understand the limitations:

• Only the Door Swing: The turning circle can only overlap the area covered by the door leaf itself. It cannot overlap other fixtures, controls, or protruding objects (e.g., a surface-mounted paper towel dispenser, a vanity, or a trash receptacle).
• Both Sides of the Door: This provision applies to maneuvering clearances on both sides of the door.
• T-Shaped Turning Space: The same principle applies to the alternative T-shaped turning space defined in ICC A117.1-2017 §304.3.2.

The parallel requirement in the 2010 ADA Standards for Accessible Design §304.4 is identical, ensuring consistency between building codes and federal law on this issue.

‍

For a roll-in shower specified under ICC A117.1, is the 30-inch by 60-inch minimum clear floor space measured from the face of the finished tile or the rough framing?

The 30-inch by 60-inch minimum clear floor space for a roll-in shower is always measured from the face of the finished surfaces. This is a fundamental principle that applies to all clear dimension requirements throughout the ICC A117.1 standard.

The relevant code section is ICC A117.1-2017 §608.2.1 (Size and Clearance for Roll-in Type Showers). The dimensions provided in the standard are for the final, usable space available to a person in a wheelchair. This means architects and contractors must account for the thickness of all wall assemblies, including:

• Waterproofing membranes
• Cement backer board
• Mortar beds
• Tile or other finished surfaces

Real-World Implication: If a shower is framed with studs placed at exactly 60 inches apart, the final finished dimension will be non-compliant. For example, two walls each with 1/2" backer board and 1/4" tile will reduce the clear width by 1.5 inches, resulting in a final dimension of 58.5 inches. To achieve a 60-inch clear dimension, the rough framing must be set wider (e.g., 61.5 inches or more) to accommodate the finishes. Design documents should always clearly label required clearances as "minimum clear" to avoid ambiguity during construction.

‍

Can a single unisex restroom containing an ambulatory-accessible toilet compartment count towards the total number of required accessible fixtures for a building under the IBC and A117.1?

Yes, a single-user unisex restroom can count toward the total number of required plumbing fixtures, but the question contains a slight misinterpretation of code terminology. A single-user restroom is not an "ambulatory-accessible toilet compartment"; it is a fully wheelchair-accessible room. An ambulatory compartment is a specific, narrower stall type found inside a multi-stall restroom.

Here is the correct application of the code:

• Fixture Counting: IBC 2024 §1110.2.1 permits single-user toilet rooms (unisex restrooms) to be counted toward the fixture counts required by the International Plumbing Code (IPC) for both males and females. This can be an efficient way to meet fixture requirements, especially in smaller buildings.
• Accessibility Requirements: To be counted, this single-user restroom must be fully accessible. This means it must meet all relevant requirements of ICC A117.1, including:

  • A 60-inch turning circle or T-shaped turning space (§603.2).
  • An accessible lavatory (§606).
  • A toilet with proper clearances, height, and grab bars (§604).
  • An accessible door, hardware, and signage.

• Ambulatory Compartments: The requirement for an ambulatory accessible compartment is triggered only in multi-user restrooms. Per ICC A117.1-2017 §604.9, when there are six or more toilets and urinals combined in a single restroom, one of the stalls must be an ambulatory accessible compartment in addition to the standard wheelchair-accessible compartment. A single-user restroom does not fulfill this specific requirement for a separate multi-user facility.

In summary, a single-user unisex restroom helps meet the total building fixture count and provides a wheelchair-accessible option, but it does not substitute for the ambulatory stall required within a large, multi-user restroom.

‍

What is the required height for a toilet seat under the A117.1 standard?

The required height for an accessible toilet seat is 17 inches minimum to 19 inches maximum, measured from the finished floor to the top of the toilet seat.

This requirement is found in ICC A117.1-2017 §604.4 (Height) and is mirrored in the 2010 ADA Standards §604.4. This specific height range is critical for facilitating safe and comfortable transfers for individuals using wheelchairs.

Important Considerations:

• Measurement Point: The measurement is to the top of the actual seat, not the rim of the bowl.
• Finished Floor: The measurement must be taken from the final installed floor surface. A common construction error is to install the toilet before the finished flooring is in place, resulting in a final height that is too low.
• Children's Facilities: For facilities designed exclusively for children's use, the A117.1 standard provides exceptions with lower height ranges based on age groups.

‍

How much clear floor space is required in an accessible bathroom?

An accessible bathroom requires multiple layers of clear floor space. The primary requirement is a general maneuvering space, and then specific clearances are mandated at each fixture. These spaces are allowed to overlap.

• Maneuvering Space (§603.2): Every accessible restroom must contain one of the following:

  • A 60-inch diameter turning circle.
  • A T-shaped turning space within a 60-inch by 60-inch square.

• Fixture Clearances: In addition to the overall maneuvering space, each fixture requires its own dedicated clear floor space:

  • Toilet (§604.3): A clear space of at least 60 inches wide measured from the side wall closest to the toilet, and 56 inches deep (for floor-mounted) or 59 inches deep (for wall-hung) measured from the rear wall.
  • Lavatory (§606.2): A clear floor space of 30 inches by 48 inches positioned for a forward approach. This space can extend underneath the sink if knee and toe clearance (§306) is provided.
  • Roll-in Shower (§608.2.1): A clear floor space of 30 inches wide by 60 inches deep minimum inside the shower compartment.
  • Transfer Shower (§608.2.2): A 36-inch by 36-inch space inside the shower, plus a 36-inch by 48-inch clear space outside the shower for transferring.
  • Bathtub (§607.2): Clear floor space of 30 inches wide minimum extending the length of the tub for a parallel approach.

‍

What is the correct mounting height for a grab bar in a shower?

The correct mounting height for horizontal grab bars in an accessible shower is between 33 inches and 36 inches above the finished floor, measured to the centerline of the grab bar's gripping surface.

This requirement is detailed in ICC A117.1-2017 §609.4 (Position of Grab Bars) and is consistent with the 2010 ADA Standards §609.4.

The specific location and configuration of grab bars depend on the type of shower:

• Transfer-Type Showers (§608.3.1): Grab bars must be installed on the back wall and the control wall. The bar on the control wall should extend to the entry.
• Roll-in Type Showers (§608.3.2): Grab bars must be installed on the back wall and the side wall opposite the shower seat. No grab bar is permitted on the control wall where a seat is provided.

Structural and Dimensional Requirements:

• Structural Strength (§609.8): The wall behind the grab bars must be reinforced to withstand a concentrated load of 250 pounds. This requires coordination with the structural design and proper blocking within the wall framing.
• Spacing (§609.3): There must be exactly 1.5 inches of clear space between the grab bar and the wall surface.
• Diameter (§609.2.1): The grab bar diameter must be between 1.25 inches and 2 inches.

‍

Common Mistakes and Misinterpretations

Even experienced professionals can make mistakes. Here are common errors to watch for in accessible restroom design:

• Toilet Centerline: The toilet must be centered 16 to 18 inches from the adjacent side wall (A117.1 §604.2). This 2-inch tolerance is strict and a frequent cause of failed inspections.
• Knee and Toe Clearance: Forgetting to protect the space under a lavatory from plumbing pipes is a common oversight. Hot water and drain pipes must be insulated or configured to prevent contact (A117.1 §606.5).
• Reach Ranges: Controls, dispensers, and outlets must be within accessible reach ranges. For example, a forward reach must be no higher than 48 inches and no lower than 15 inches from the floor (A117.1 §308).
• Door Pressure and Closing Speed: An accessible door must meet requirements for opening force (typically 5 pounds) and have a closer that takes at least 5 seconds to move from 90 degrees to 12 degrees (A117.1 §404.2.8 & §404.2.9).
• Mirror Height: The bottom edge of a required mirror's reflecting surface must be no higher than 40 inches above the finished floor (A117.1 §603.4).

‍

Jurisdictional Variations: Beyond the Model Codes

While the IBC and A117.1 provide a national baseline, many states and large cities adopt their own amendments that can be more restrictive. It is essential to verify local requirements.

• California (CBC): California has its own accessibility codes in the California Building Code (CBC) Chapters 11A and 11B, which contain numerous unique provisions for items like door maneuvering clearances, restroom signage, and grab bar locations.
• Texas (TAS): The Texas Accessibility Standards (TAS) are enforced by the Texas Department of Licensing and Regulation and have specific requirements that sometimes differ from the ADA and A117.1.
• Florida (FBC): The Florida Building Code, Accessibility, contains state-specific modifications to the model codes.

Always consult the adopted code for the specific jurisdiction of your project. When in doubt, design to the most restrictive requirement between the local code, the IBC/A117.1, and the 2010 ADA Standards.

‍

Permitting and Plan Review

During plan review, examiners will look for explicit compliance with A117.1. Your construction documents should:

• Clearly label all required clearances (e.g., "60-inch Dia. Turning Circle," "30x48 Clear Floor Space").
• Dimension fixtures from finished surfaces, not centerlines of walls.
• Provide enlarged plans and elevations of accessible restrooms showing all dimensions, fixture heights, and accessory locations.
• Include a note on the drawings requiring structural blocking for all grab bars and wall-mounted fixtures.
• Specify compliant fixtures and hardware in your schedules.

A complete and clearly detailed drawing set demonstrates due diligence and significantly streamlines the permitting process.

‍

FAQ Section

What is the difference between ANSI A117.1 and the ADA?

ICC A117.1 is a technical standard adopted by building codes that provides the "how-to" for accessible design. The ADA is a federal civil rights law that mandates accessibility in public accommodations. The 2010 ADA Standards for Accessible Design is the ADA's own technical standard. The two documents are very similar, but A117.1 is enforced by building officials, while the ADA is enforced by the Department of Justice.

‍

Is a trash can allowed to be in the 60-inch turning circle?

No. The turning circle must be kept clear of all obstructions, including movable items like trash cans. If a trash can is provided, it must be located outside the minimum required clear floor spaces and turning circles.

‍

What are the reach range requirements in an accessible restroom?

Generally, for a forward reach over no obstruction, the range is 15 inches minimum to 48 inches maximum above the floor. For a side reach, the maximum height is also 48 inches. This applies to light switches, outlets, and dispensers for soap, paper towels, and toilet paper.

‍

Are circular or rounded front toilets allowed in accessible stalls?

No. Accessible water closets must have an elongated bowl (ICC A117.1-2017 §604.2).

‍

What is the required clear opening width for an accessible restroom door?

The minimum clear opening width is 32 inches, measured from the face of the door to the stop of the frame when the door is open 90 degrees (ICC A117.1-2017 §404.2.3).

‍

Do I need a vertical grab bar in a shower?

While not required in all showers, ICC A117.1-2017 §608.3.1.3 requires an 18-inch vertical grab bar to be installed at the entrance to a transfer-type shower stall.

‍

How high should an accessible sink be?

The front rim or counter surface of an accessible lavatory must be no higher than 34 inches above the finished floor (ICC A117.1-2017 §606.3).

‍

What kind of faucet handles are required?

Faucet controls must be operable with one hand, not require tight grasping, pinching, or twisting of the wrist, and require no more than 5 pounds of force to activate. Lever-operated, push-type, and electronically controlled mechanisms are all acceptable options (ICC A117.1-2017 §309.4).

‍

Are automatic door openers required for accessible restrooms?

Generally, no. Automatic door openers are not required by A117.1 or the ADA for most restroom doors, provided the door meets the requirements for opening force, closing speed, and has accessible hardware. They are often provided as an enhancement or in specific occupancies like hospitals.

‍

Can I use a pocket door for an accessible restroom?

Yes, a pocket door can be used, but it must meet all accessibility criteria. This includes a 32-inch clear opening width, hardware that is usable without tight grasping (like a C-pull), and it must be easy to open and close. Achieving these requirements with a pocket door can be challenging and often requires specialized hardware.

‍

References

1. ICC A117.1–2017: Accessible and Usable Buildings and Facilities (Official Standard – Digital Viewer): https://codes.iccsafe.org/content/icca117-12017/american-national-standard
2. IBC 2021 – Chapter 11 Accessibility (Scoping for Accessible Restrooms and Bathing Rooms: https://codes.iccsafe.org/content/IBC2021P1/chapter-11-accessibility
3. U.S. Access Board – ADA Accessibility Guidelines (ADAAG): Bathrooms, Toilets & Bathing Facilities: https://www.access-board.gov/ada/guides/chapter-6-plumbing-elements-and-facilities/

‍
