What are the major updates in NEC 2023 vs. 2020 & 2017?

The 2023 Edition of the National Electrical Code (NFPA 70) introduces significant updates focused on improving electrical safety, adapting to new technologies, and increasing the resiliency of electrical systems. For architects, engineers, and contractors, understanding these revisions is critical for ensuring compliance, passing plan review, and avoiding costly field corrections.

Key high-impact changes in the NEC 2023 include:

• Expanded AFCI Protection: Arc-Fault Circuit Interrupter (AFCI) requirements in §210.12 have been expanded to include more areas in dwelling units and now apply to certain common areas and public spaces in commercial buildings.
• Mandatory Emergency System Commissioning: A new requirement in §700.3(F) mandates formal commissioning for emergency systems, including documented testing of all components to ensure they function as a complete system.
• Reorganized Energy Storage Systems (ESS): Article 706 for Energy Storage Systems has been completely restructured for clarity, with new requirements for disconnecting means and system labeling that better align with other safety standards like NFPA 855.
• Broader Surge Protection (SPD) Rules: The requirement for Surge Protective Devices (SPDs) for dwelling unit services (§230.67), introduced in 2020, has been clarified and expanded in 2023 with a new requirement for SPDs on dwelling unit feeders (§215.18).
• Exterior Emergency Disconnects: The requirement for an exterior emergency disconnect for one- and two-family dwellings (§230.85), first seen in NEC 2020, is a critical safety measure for first responders that continues in the 2023 code.
• Expanded GFCI Protection: The scope of Ground-Fault Circuit-Interrupter (GFCI) protection continues to expand, with §210.8 requiring protection for all 125-volt through 250-volt receptacles in locations like kitchens, bathrooms, garages, and outdoor areas.

Why Staying Current with the NEC Matters

The National Electrical Code (NEC), or NFPA 70, is the benchmark for safe electrical design, installation, and inspection in the United States. It is updated every three years by the National Fire Protection Association (NFPA) to address emerging technologies (like EVs and energy storage), incorporate new safety research, and clarify existing rules.

However, the NEC is a model code. Its legal authority comes from being adopted by states, counties, and cities, often with significant local amendments. This creates a complex compliance landscape where a designer may be working under the 2017 NEC in one county and the 2023 NEC in another.

Understanding the evolution of the code is crucial for:

• Future-Proofing Designs: Designing to the newest code, even before local adoption, can prevent costly redesigns when a jurisdiction updates its requirements mid-project.
• Ensuring Safety: The code changes are not arbitrary; they reflect lessons learned from field incidents, fires, and electrical shock events.
• Passing Plan Review & Inspections: Jurisdictions and their inspectors are focused on enforcing the adopted code. Submitting plans based on an outdated version is a primary cause of permit rejection and project delays.
• Inter-Disciplinary Coordination: Electrical requirements in the NEC directly impact other disciplines. Architects must account for space for larger switchgear and exterior disconnects, while mechanical engineers must coordinate power requirements and disconnect locations for HVAC equipment.

What are the most significant changes in the NEC 2023 impacting commercial electrical system design, specifically regarding AFCI requirements, emergency systems, and energy storage systems, compared to the NEC 2020?

The NEC 2023 introduces substantial changes for commercial projects that build upon the 2020 code. The most significant updates focus on expanding arc-fault protection into public areas, formalizing the testing of emergency systems, and completely reorganizing the rules for energy storage to improve clarity and safety.

AFCI Requirements (Article 210)

The NEC 2023 expands the use of AFCI protection beyond its traditional focus on dwelling units.

• NEC 2023 §210.12(C) now requires AFCI protection for 120-volt, single-phase, 15- and 20-ampere branch circuits supplying outlets and devices in specific non-dwelling locations.
• New Locations Include:
  • Areas designed for use by the public in schools, such as classrooms and offices.
  • Common rooms in dormitories and similar residential institutional facilities.
  • Patient sleeping rooms in nursing homes and limited-care facilities.
• This is a notable expansion from NEC 2020 §210.12, which primarily mandated AFCI in dwelling units, dormitory units, and hotel/motel guest rooms. This change requires designers to specify AFCI breakers or receptacles in a wider range of commercial settings, impacting panelboard schedules and budgets.

Emergency Systems (Article 700)

A major change in NEC 2023 is the introduction of a formal commissioning process for emergency systems, ensuring all parts work together as intended.

• NEC 2023 §700.3(F) Commissioning: This new section requires a "thorough commissioning of the emergency system" upon completion. This includes a documented process of functional performance tests to verify the system operates in accordance with design and applicable codes. This goes beyond the simple "testing" required in previous editions.
• NEC 2023 §700.10(D) Emergency Shutdown: This section adds a requirement for a readily accessible emergency shutdown means for prime movers and energy storage systems used as alternate power sources. The shutdown must be located outside the equipment room, adding a new design consideration for generator and battery room layouts.

Energy Storage Systems (ESS) (Article 706)

Article 706 was completely rewritten and reorganized for the 2023 cycle to improve usability and align with other industry standards like NFPA 855.

• Reorganization: The article is now structured more logically, making it easier to find requirements for installation, disconnecting means, and specific technologies.
• ESS Disconnecting Means (§706.15): The requirements for disconnecting an ESS have been clarified. It now mandates a single disconnecting means to isolate the ESS from all other energized conductors, whether from the utility, PV systems, or other sources. The location and labeling requirements for this disconnect are more explicit.
• Labeling (§706.10): The requirements for marking and labeling ESS have been enhanced to provide first responders with clearer information about the system's presence, shutdown procedures, and potential hazards.

My jurisdiction is still on the 2017 NEC but is planning to adopt the 2023 NEC next year. What are the top five high-impact changes I need to incorporate into my designs now to future-proof our projects for permitting?

To bridge the gap between the 2017 and 2023 NEC and avoid future permitting issues, designers should proactively incorporate five major changes that were introduced in the 2020 and 2023 code cycles. These changes represent significant shifts in safety philosophy and are highly likely to be enforced upon adoption.

1. Expanded GFCI Protection for Receptacles: The scope of GFCI protection has grown dramatically since 2017. NEC 2023 §210.8(A) and (B) now require GFCI for nearly all 125-volt through 250-volt receptacles in locations like kitchens, bathrooms, garages, basements, laundry areas, and outdoors. The 2017 code was far more limited, typically only applying to 125-volt, 15- and 20-amp receptacles in specific areas. Designing to the 2023 standard now means planning for more GFCI circuit breakers or receptacles in both residential and commercial projects.
2. Mandatory Surge Protective Devices (SPDs) for Dwelling Units: This is one of the biggest changes from the 2017 code. NEC 2023 §230.67 mandates a Type 1 or Type 2 SPD for all new or replaced services supplying dwelling units (single-family homes, apartments, etc.). Furthermore, NEC 2023 §215.18 adds a requirement for SPDs on feeders that supply dwelling units, such as in a multi-family building. The 2017 NEC had no such requirement for standard services. This impacts panelboard and switchboard specifications immediately.
3. Exterior Emergency Disconnect for Dwelling Units: A major life-safety feature introduced in NEC 2020 §230.85 and carried into the 2023 code, this rule requires an emergency disconnect to be installed in a readily accessible outdoor location for all new or replaced services at one- and two-family dwellings. This "firefighter disconnect" allows first responders to de-energize the home quickly and safely. This was not present in the 2017 NEC and requires coordination with architects for placement and aesthetics.
4. Expanded AFCI Protection in Dwelling Units: While the 2017 NEC already required AFCI in many areas, the 2020 and 2023 codes expanded it further. NEC 2023 §210.12(A) now includes basements in the list of required locations. Incorporating AFCI protection for all 120-volt, 15- and 20-amp branch circuits in all dwelling unit areas (including kitchens, laundries, and basements) is the best way to future-proof a design.
5. Updated Energy Storage System (ESS) Requirements: Article 706, which covers systems like the Tesla Powerwall, was new in 2017. It has been heavily revised in both the 2020 and 2023 NEC. Designing an ESS installation based on the 2017 rules will not pass under the 2023 code. Key changes to incorporate now include the updated disconnecting means requirements in §706.15 and the more robust labeling and signage rules in §706.10.

For a new multi-family residential project in California, what specific articles from the California Electrical Code (CEC) supersede or significantly amend the NEC 2020/2023 requirements for load calculations, EV charging infrastructure, and common area lighting?

Designing a multi-family project in California requires adherence to the California Electrical Code (CEC), which is based on the NEC but includes critical amendments. Furthermore, compliance is heavily influenced by the California Energy Code (Title 24, Part 6) and the California Green Building Standards Code (CALGreen, Title 24, Part 11).

Load Calculations (CEC Article 220)

While the CEC generally follows NEC Article 220 for load calculations, engineers must be cautious. The CEC may not adopt certain permissive sections or optional calculation methods from the model NEC. For example, demand factors for cooking equipment or other loads might be amended. The most critical step is to perform all calculations based on the specific version of the CEC adopted at the time of permit submittal, not just the model NEC. Always verify with the local Authority Having Jurisdiction (AHJ) for any local amendments that may be even more stringent.

EV Charging Infrastructure (CEC Article 625 & CALGreen)

This is where California law dramatically supersedes the model NEC. While the CEC adopts NEC Article 625 for the safety of Electric Vehicle Supply Equipment (EVSE), the quantity and type of required EV infrastructure are mandated by CALGreen.

• CALGreen §4.106.4 (for new multi-family dwellings) sets specific requirements based on the total number of parking spaces. The requirements are tiered:
  • EV Capable: A percentage of spaces must have the raceway and panel capacity installed for future EVSE.
  • EV Ready: A smaller percentage must have a full circuit with a 208/240V receptacle or termination point installed.
  • EVSE Installed: Some jurisdictions require a certain number of chargers to be installed and operational from day one.
• These CALGreen mandates significantly impact the electrical service size, distribution design, and switchgear configuration. Engineers must use load management systems, as permitted by CEC §625.42, to meet these requirements without drastically oversizing the service.

Common Area Lighting (CEC & Title 24, Part 6)

The safety of lighting installations (wiring, connections) is governed by the CEC. However, the energy performance, fixture efficacy, and control strategies for all lighting, including common areas like corridors, lobbies, garages, and exterior spaces, are strictly regulated by the California Energy Code (Title 24, Part 6).

• Lighting Power Density (LPD): Title 24, Part 6 sets maximum allowable lighting power in watts per square foot for different space types. The design must not exceed these LPDs.
• Mandatory Controls: The energy code mandates advanced lighting controls far beyond NEC requirements. This includes multi-level lighting controls, occupancy sensors (vacancy sensors in some cases), daylighting controls for areas with windows or skylights, and automatic scheduling.
• Compliance requires a separate set of energy calculations (often using state-certified software) to be submitted with the permit documents, demonstrating adherence to these strict efficiency and control requirements.

How have the requirements for surge protection devices (SPDs) evolved from the NEC 2017 to NEC 2023 for both residential and commercial services, and what is the design impact for switchboard and panelboard specifications?

The requirements for SPDs have undergone one of the most significant evolutions in recent NEC cycles, moving from a niche requirement to a standard safety feature for many occupancies. This directly impacts how engineers specify service entrance and distribution equipment.

SPD Requirement Evolution: NEC 2017 to 2023

NEC CycleKey SPD RequirementCode SectionDesign ImpactNEC 2017Required only for specific critical systems like legally required standby systems and fire pump controllers. Not required for standard dwelling or most commercial services.§701.8, §695.15Minimal impact on typical projects. SPDs were specified on an as-needed or optional basis.NEC 2020Landmark Change: Mandated a Type 1 or Type 2 SPD for all new and replaced electrical services supplying dwelling units (one-family, two-family, and multi-family).§230.67Major Impact: All dwelling unit service entrance equipment must now include surge protection. This became a standard specification item.NEC 2023Retained the §230.67 requirement and expanded it by adding a new requirement for SPDs on feeders supplying dwelling units. This covers panelboards in multi-family buildings that are downstream of the main service.§230.67, §215.18Expanded Impact: Not just the main service, but also feeder panelboards supplying dwelling units now require SPDs. Requirements for other commercial systems (e.g., elevators, industrial machinery) were also clarified and added.

Design and Specification Impact

This evolution has fundamentally changed the specification process for switchboards and panelboards:

1. Standard Specification: For any project involving dwelling units, specifying an integral SPD within the service or distribution panelboard is now standard practice. Most major manufacturers (Eaton, Siemens, Square D) offer factory-installed SPDs as a common option.
2. Space Planning: If an external SPD is used, designers must allocate dedicated wall space near the panel and plan for short, straight conductor runs to ensure the SPD performs effectively, as required by NEC §242.12.
3. Renovation Projects: The requirement applies to "service replacements," not just new construction. Any project that involves replacing an existing service panel at a dwelling will trigger the need to add an SPD, which must be factored into the project scope and budget.
4. Budgeting: SPDs add a material and labor cost that was previously optional. This cost must be included in electrical estimates from the initial design phase to avoid budget overruns.
5. Submittals and Plan Review: Electrical drawings and equipment submittals must clearly show compliance with the SPD requirements. Plan reviewers will look for the SPD on single-line diagrams and in the panelboard specifications.

Common Mistakes and Misinterpretations

• Ignoring Local Amendments: The most common mistake is designing a project based on the model NEC without verifying local city or state amendments. This can lead to complete plan rejection. Always start by confirming the adopted code and amendments with the local AHJ.
• Confusing AFCI and GFCI: These are not interchangeable. GFCIs protect against shock hazards (ground faults), while AFCIs protect against fire hazards (arcing faults). Many locations, like kitchens and laundry rooms, now require both forms of protection.
• Misinterpreting "Receptacle Replacement": Per NEC §406.4(D), when you replace a receptacle in a location where GFCI or AFCI protection is now required, you must install a protected receptacle or ensure the circuit has a protective breaker, even if the original installation did not require it. This is a common point of failure during inspections on renovation projects.
• Forgetting Working Space Clearances: NEC §110.26 defines mandatory working clearances in front of and around electrical equipment. These requirements often conflict with architectural layouts. This must be coordinated early in the design phase to ensure adequate, dedicated space for electrical gear.

Best Practices for Code Compliance

• Establish the Code Baseline Early: At the start of any project, identify the exact code editions (NEC, IBC, IFC, IECC) and all local amendments adopted by the AHJ.
• Develop a Code Compliance Checklist: Create a project-specific checklist that flags key requirements like GFCI/AFCI, SPD, emergency disconnects, and EV charging. Review this checklist at each design milestone.
• Engage a Code Consultant: For large or complex projects, especially in jurisdictions with extensive amendments like California or New York City, a code consultant can provide invaluable insight and prevent costly errors.
• Coordinate with Other Disciplines: Hold regular coordination meetings with architectural, mechanical, and plumbing teams. Discuss equipment locations, power requirements, disconnect locations, and clearances to prevent conflicts in the construction documents.
• Document Everything: Clearly note all code-related decisions and requirements on your drawings. This helps the plan reviewer, contractor, and inspector understand the design intent and verify compliance.

Frequently Asked Questions (FAQ)

What is the difference between NFPA 70 and the NEC?

‍There is no difference. The National Electrical Code (NEC) is the title of the document, and it is published by the National Fire Protection Association (NFPA) as standard number 70. The terms NFPA 70 and NEC are used interchangeably.

When will the next NEC (2026) be released?

‍The NEC is on a three-year revision cycle. The development process for the 2026 NEC is currently underway, and it is expected to be published in the fall of 2025.

Is an SPD the same thing as a plug-in surge protector strip?

‍No. An SPD required by the NEC (Type 1 or Type 2) is installed at the service panel or switchboard to protect the entire electrical system from external surges like lightning or utility switching. A plug-in surge strip is a point-of-use device that offers a secondary, lower level of protection for specific electronics.

Do I need to GFCI-protect a refrigerator in a residential kitchen?

‍Yes. Under the NEC 2020 and 2023, all 125-volt through 250-volt receptacles in a kitchen, regardless of what they serve, require GFCI protection as per NEC §210.8(A)(6).

Are the NEC code changes retroactive?

‍Generally, no. The NEC applies to new construction, additions, and significant renovations or alterations. Existing installations that were compliant when built are typically "grandfathered" in, unless a specific hazard is identified by the AHJ or a renovation project triggers an upgrade requirement.

What is a "Class 4" power system in the new NEC 2023?

‍New Article 726 in the NEC 2023 introduces Class 4 power systems, also known as fault-managed power systems or "smart power." These systems use advanced monitoring and control to limit the amount of energy available during a fault, allowing them to deliver higher power levels over longer distances than PoE (Power over Ethernet) while still being considered safe from a shock and fire perspective.

Where can I find my state's specific electrical code and amendments?

‍Most states publish their adopted codes and amendments on the website of their Department of Building Safety, Division of Fire Safety, or professional licensing board. A web search for "[Your State] electrical code" will typically lead to the correct government agency website.

‍
